5ton 15m European Style Single Girder Wire Rope Hoist

MOQ: one set
Price: USD1,000-5,000
Standard Packaging: Wooden Box Packaging
Delivery Period: 20 Working Days
Payment Method: MoneyGram, Western Union, T/T, D/P, D/A
Supply Capacity: 1000 Sets One Year
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
kiwicrane
Certification
ISO、CE
Model Number
VTS
Lifting Capacity:
5000KG
Lifting Height:
15M
Power:
220-460V 50/60hz 3 Phase
Warranty:
1 Year
Production Name:
European Style Single Beam Electric Wire Rope Hoist 5T 15M
Usage:
Construction Hoist,Mining Hoist,Bridge Crane,Lifting Moving Mater
Condition:
New
Sling Type:
Wire Rope
Lifting Speed:
5/0.8m/min
Application:
Construction Site Lifter,warehouse And So On,Single Girder Crane Use
Color:
Yellow
Travel Speed:
20/5 M/Min
Hook:
Forged Steel
Customization:
Yes
Highlight:

5t Single Girder Wire Rope Hoist

,

15m Single Girder Wire Rope Hoist

Product Description

5ton 15m European style single girder wire rope hoist



model   VTW-S 5T
SWL t 5
lifting height m 15
lifting speed m/min 0.8/5.0
travel speed m/min 5-20
power in V;HZ 220~460V 50/60Hz
FEM(GB) -- 2m(M5)
lifting motor power KW 1.0/6.1
RPM n/min 420/2840
insulation -- F
production -- IP55
duration -- 40%
rated current   5.17/14.20
lift gear ratio -- 67.59
drum dia mm 190
wire rope -- 8-8*26(WS)+IWRC
travel motor power in KW 0.4*2
RPM n/min 104
insulation -- F
production -- IP55
duration --
rated current A 2.35
wheel dia mm 100



1,High safety:

Dual brake system: This is a key safety configuration. Usually includes:

Disc brake: Located at the tail of the motor, sensitive response and good heat dissipation.

Mechanical (or electromagnetic) safety brake: Located on the high-speed shaft of the reduction gearbox or on the drum, as a second safety guarantee, it can brake reliably even if the disc brake fails.

Multiple limit protection:

Lifting upper limit switch: Mechanical (lever type) or electronic (absolute encoder) to prevent over-winch.

Lifting lower limit switch: (usually optional).

Running limit switch: (usually installed on the crane end beam or track end block).

Overload protection: Some models can be equipped with an electronic overload limiter.

Wire rope anti-slip groove device: Ensure that the wire rope is properly wound on the drum.

Hook anti-slip device: Meets safety standards.

5ton 15m European Style Single Girder Wire Rope Hoist 0



2,Modular design:

The design concept of European hoists is modularization and standardization. The core components such as motor, reduction box, drum device, limiter, brake, electric control box are relatively independent and easy to disassemble and replace.

Benefits: Easy to maintain and replace parts, shorten downtime; easy to combine and configure according to different needs (tonnage, lifting height, speed, control method); good versatility of spare parts.
